Frame |
Custom 7005 Aluminum
Trail-Tuned POWER STAY frame, box section chainstays, bi-axial
gussetted downtube, sculpted rear dropouts with replaceable rear
derailleur hanger, 2x H2O
bosses, International Standard rear disc mounts |
Fork |
LOCKOUT Equipped, Suntour XCT V2 long-travel, Adjustable Preload |
Crankset |
TruVativ Isoflow
Aluminum arms 175mm,
Triple Rings 22/32/42T |
Bottom Bracket | Sealed Cartridge |
Pedals |
ATB Beartrap |
Front Derailleur |
Shimano Acera top swing
|
Rear
Derailleur |
Shimano Deore long
cage |
Shifters |
Shimano ST-EF50BR STI
EZFire with Optical Gear Indicators (24 speeds total) |
Cassette/Freewheel |
Cassette 11-28T 8 speed
(24 speeds total) |
Chain |
KMC Z72
Narrow 8 speed |
Hubs |
Formula Disc-Specific for 6-bolt rotors, Forged
Aluminum,
Black Anodized, Rubber Labyrinth Sealed Ball Bearing |
Spokes |
Stainless Steel |
Rims |
WTB Speed Disc - Double Wall Aluminum, Anodized |
Tires |
WTB Velociraptor
Blackwall 26 x 2.10 (front and rear specific tread) |
Brakes |
TEKTRO
IO Mechanical Disc Brakes with Multi Pad Angle adjustments |
Brake
Levers | Shimano ST-EF50BR STI
EZFire with Optical Gear Indicators (24 speeds total) |
Headset |
Cane Creek Internal
Sealed caged ball bearing VP A42E 1.125 inch |
Handlebar |
Skye Comp Aluminum
Riser |
Stem |
Skye Comp Threadless
Aluminum for 1.125" Threadless steerer |
Tape/Grip |
WTB Dual Compound |
Saddle |
WTB Speed V with
comfort groove |
Seat Post |
Skye Aluminum
Micro-Adjust, 27.2mm |
Seat
Clamp | Alloy w/QR |
Sizes |
13, 15, 17, 19, 21, 23 inch Geometry Sizing Chart |
Colors |
StarBlue (as shown) or JewelWhite StarBlue Pics | JewelWhite Pics |
Our
low price is $379.95 Compare at $795 MSRP
This
bike comes up to 90 percent
assembled. If you don't feel confident working on your bike, we suggest
you take it to your local bike shop for final assembly
& safety checks.
How much Assembly?
CLICK
HERE to see sample assembly instructions and a video (scroll
to bottom)
CLICK HERE for your special price on the full Video DVD/CD and Folding
Mini Tool Kit |
