| Main
Frame |
Windsor custom butted 4130 Cro-Moly, Double water bottle mounts
|
| Rear
Triangle |
Windsor custom tapered Cro-Moly with forged dropout, Spare spoke
holder (spares not included), rack mounts, 130mm rear spacing |
| Fork |
Windsor custom tapered Cro-Moly, front Rack Brazeons |
| Crankset |
FSA VERO TRIPLE / 50/39/30T / POL SLV w/FSA LOGO (170mm 49 / 54 / 175mm 56 / 58 / 64) |
| Bottom Bracket |
CH-52 / 68mm CARTRIDGE / JIS / w/BOLTS |
| Pedals |
9/16" BORON AXLE / ALLOY SLV BODY / BLK CAGE w/MEDIUM RP-1 CLIP w/STRAP w/BS REFL |
| Front Derailleur |
Shimano SORA 3-SPEED w/28.6mm ADAPTER |
| Rear Derailleur |
Shimano Deore, 9-speed |
| Shifters | Shimano SORA, 9-speed STI |
| Cassette/Freewheel |
SRAM PG950 9-speed,
11-32T |
| Chain |
HG73 9-SPEED LINKS / w/END PIN |
| Front Hub |
Windsor Sealed Alloy
Road, 36H ALLOY / 36H / SEALED BEARING / w/QR |
| Rear
Hub |
ALLOY / 36H / SEALED BEARING / w/QR, 130mm rear spacing |
| Spokes |
Stainless, 14g |
| Rims |
Double
Wall Aluminum, 36H, ATB 220 700c x 36H F/V w/CNC SIDES |
| Tires |
Kenda
Eurotrek, 700 x 32c, presta valve tubes |
| Brake Set |
Tektro
992A FORGED ALLOY CANTI BRAKE 836.12 63mm EN PAD |
| Brake Levers |
Shimano SORA, 9-speed STI |
| Headset |
1 1/8" / STEEL / CAGED BEARINGS w/FSA LOGO / TRI-03 ALLOY 2 PIECES FOR FRONT AND REAR
FRT CABLE HANGER |
| Handlebar |
Butted Road, Anatomical Drops, ALLOY / W 420mm / C 25.4mm 49 / 54
/ W 440mm / C 25.4mm 56 / 58 / 64 |
| Stem |
Windsor
Superlight Road Aluminum, 10d / E 100mm / C 25.4, 49 / 54
10d / E 110mm / C 25.4, 56 / 58 / 64 |
| Tape/Grip |
Windsor custom cork
wrap Black |
| Saddle |
Windsor Sport "Crater"
Touring |
| Seat
Post |
Superlite Micro Adjust alloy, 250mm, 27.2 |
| Seat Clamp |
New
Windsor Ultralite alloy, Lazer etched, ALLOY / 29.8mm w/ M5 STAINLESS BOLT |
| Sizes |
see pull down |
| Colors | see pull down |
| Our
low price Saves You Hundreds Compare
at $1200
FACTORY DIRECT PRICES SAVE YOU Over $700 Off!
+FREE REAR ALUMINUM RACK WITH STAINLESS HARDWARE
+FREE GROUND SHIP TO 48 STATES This bike comes up to 90 percent
assembled.
We suggest you take it to your local bike shop for final assembly
& safety checks. |
